WOSSNER PISTON KIT 2013 EC300F 83.00 A, WOSSNER 8875DA

Piston KIT 83mm BORE 82.94mm Wossner 8875DA (STD)
GASGAS
EC300F 2013 -,

Wossner forged pistons are superior in strength and design. Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls. Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse. Made in Germany. PART NO. 56-W912.A.WO (ORO2U.COM)WOSSNER PISTON KIT 8875DA
GASGAS EC300F 2013 (4-STROKE)
SIZE 82.94mm
Lock P/N CW16
Pin P/N WP059
Ring Set P/N 830XDS Display (cm3) 290
Hub stroke (mm) 53.60
Clearance (mm) 0.06
Wossner compression Ratio: OEM
OEM Compression ratio: 13.50:1
Dome volume (cm3) -6.30
Compression height (mm) 22.20
Theorectical weight (G)
